Anti Corruption Low Pressure 316L Metal Intalox Saddles
Anti Corruption low pressure 316L metal intalox saddles.
1.Specification.
|
Model |
Intalox Saddles |
||||||
|
Material |
Carbon Steel; SS 304, 304L, 410, 316, 316L, etc. |
||||||
|
Size |
mm |
15 |
25 |
40 |
50 |
60 |
70 |
|
Thickness |
mm |
0.3 |
0.3 |
0.3 |
0.4 |
0.4 |
0.5 |
|
Bulk density |
kg/m3 |
282 |
222 |
147 |
133 |
109 |
114 |
|
Number |
per m3 |
347000 |
135000 |
50200 |
15000 |
8400 |
4600 |
|
Free volume |
% |
96.5 |
96.8 |
97.1 |
98.1 |
98.2 |
98.6 |
|
Surface Area |
m2/m3 |
305 |
241 |
161 |
104 |
85 |
62 |
|
Packing Factor |
m-1 |
167 |
135 |
79 |
59 |
50 |
39 |
|
Typical Application |
Absorption, scrubbing and stripping services |
||||||
2. Advantage:
■ A versatile packing used in distillation, absorption and other operations.
■ Used in both deep vacuum and high pressure towers.
■ Chemxin metal saddle is high performance random packing successfully used in mass transfer towers both small and large diameter. It is frequently used in deep vacuum towers where low pressure drop is crucial and also high pressure towers where capacity significantly exceeds conventional trays.
Package & Shipment.
Production Process.
Company information.
Certificate.
FAQ.
1).How much quantity sample can be free?
---Around 500g.
2). What's your product package?
---Our normal package is 25kg carton,we can also packed with steel drum,paper drum.
3). What's your MOQ?
---We are very flexible to small orders.
4). What certificate you have?
---ISO9001 SGS etc
Product Series.
Contact way.
E-mail: info@chemxin.com
Many thanks for browsing! Welcome your inquiry! Any of your questions will get our prompt attention & reply.
